F-5 Tiger

9,966 Pakdaaircraftindustries  one month ago

Aircraft:

The Northrop F-5 is a family of supersonic light fighter aircraft initially designed as a privately funded project in the late 1950s by Northrop Corporation. There are two main models: the original F-5A and F-5B Freedom Fighter variants, and the extensively updated F-5E and F-5F Tiger II variants. The design team wrapped a small, highly aerodynamic fighter around two compact and high-thrust General Electric J85 engines, focusing on performance and a low cost of maintenance. Smaller and simpler than contemporaries such as the McDonnell Douglas F-4 Phantom II, the F-5 costs less to procure and operate, making it a popular export aircraft. Though primarily designed for a day air superiority role, the aircraft is also a capable ground-attack platform. The F-5A entered service in the early 1960s. During the Cold War, over 800 were produced through 1972 for US allies. Despite the United States Air Force (USAF) not needing a light fighter at the time, it did procure approximately 1,200 Northrop T-38 Talon trainer aircraft, which were based on Northrop's N-156 fighter design.

After winning the International Fighter Aircraft Competition, a program aimed at providing effective low-cost fighters to American allies, in 1972 Northrop introduced the second-generation F-5E Tiger II. This upgrade included more powerful engines, larger fuel capacity, greater wing area and improved leading-edge extensions for better turn rates, optional air-to-air refueling, and improved avionics, including air-to-air radar. Primarily used by American allies, it remains in US service to support training exercises. It has served in a wide array of roles, being able to perform both air and ground attack duties; the type was used extensively in the Vietnam War.[2] A total of 1,400 Tiger IIs were built before production ended in 1987. More than 3,800 F-5s and the closely related T-38 advanced trainer aircraft were produced in Hawthorne, California.[3] The F-5N/F variants are in service with the United States Navy and United States Marine Corps as adversary trainers.[4] Over 400 aircraft were in service as of 2021.[5][N 1]

The F-5 was also developed into a dedicated reconnaissance aircraft, the RF-5 Tigereye. The F-5 also served as a starting point for a series of design studies which resulted in the Northrop YF-17 and the F/A-18 naval fighter aircraft. The Northrop F-20 Tigershark was an advanced variant to succeed the F-5E which was ultimately canceled when export customers did not emerge.

Load-out

X2 : AIM-9 Side Winder Air-to-air Missiles
X2 : 20 mm (0.787 in) M39A2 Revolver cannon
X1 : External Fuel tank (175 gallons)

Spotlights

General Characteristics

  • Successors 1 airplane(s) +7 bonus
  • Created On Android
  • Wingspan 40.1ft (12.2m)
  • Length 73.6ft (22.4m)
  • Height 20.6ft (6.3m)
  • Empty Weight 14,086lbs (6,389kg)
  • Loaded Weight 21,203lbs (9,617kg)

Performance

  • Power/Weight Ratio 1.059
  • Wing Loading 36.2lbs/ft2 (176.9kg/m2)
  • Wing Area 585.3ft2 (54.4m2)
  • Drag Points 5750

Parts

  • Number of Parts 84
  • Control Surfaces 5
  • Performance Cost 435
