Tecnam P2010 Meraj Aviation Flight Academy

41.8k Decembermin  3 months ago
Auto Credit Based on MAPA's Tecnam P2010 / P2008

The Tecnam P2010 is a larger, four seat relative of the Tecnam P2008 two seat braced high wing light aircraft. Both types have metal wings and tailplane on a composite fuselage with integrated fin.[2]
The wing leading edge is straight except for some pinching at the root and the wing has constant chord on the inner section. Outboard, the trailing edge is tapered; the straight wing tips are slightly upturned. Ailerons span the outboard panels and the inner sections carry flaps. There is a single lift strut on each side, attached to the lower fuselage. The P2010 has a low set all-moving constant-chord tailplane with an anti-balance tab. The fin is swept and the rudder moves above the tailplane.[2]
The P2010 is powered by a 135 kW (180 hp) Lycoming IO-360-M1A horizontally opposed four cylinder piston engine, with a 215 hp Lycoming IO-390 option available.[3] The cabin seats the pilot and three passengers in two side-by-side rows, accessed by three doors. Its fixed tricycle undercarriage has spring cantilever main legs and a castoring nosewheel. All wheels have speed fairings.

Real Photo:



Credit to @ MAPA's for his original Tecnam P2010 / P2008

Spotlights

General Characteristics

  • Predecessor Tecnam P2010 / P2008
  • Created On iOS
  • Wingspan 40.0ft (12.2m)
  • Length 30.3ft (9.2m)
  • Height 11.7ft (3.6m)
  • Empty Weight N/A
  • Loaded Weight 3,495lbs (1,585kg)

Performance

  • Horse Power/Weight Ratio 0.143
  • Wing Loading 10.3lbs/ft2 (50.2kg/m2)
  • Wing Area 339.7ft2 (31.6m2)
  • Drag Points 2452

Parts

  • Number of Parts 177
  • Control Surfaces 5
  • Performance Cost 685
