Tupolev SB (ANT-40)

14.9k Onat67  9 months ago

The Tupolev ANT-40, also known by its service name Tupolev SB and development co-name TsAGI-40, was a high speed twin-engined three-seat monoplane bomber, first flown in 1934. The Tupolev design was advanced but lacked refinement, much to the dismay of crews, maintenance personnel, and Stalin, who pointed out that "there are no trivialities in aviation".

Numerically the most important bomber in the world in the late 1930s, the SB was the first modern stressed skin aircraft produced in quantity in the Soviet Union and probably the most formidable bomber of the mid-1930s. It was produced in the Soviet Union and was also built under license in Czechoslovakia. Many versions saw extensive action in Spain, the Republic of China, Mongolia, Finland and at the beginning of World War II against Germany in 1941. It was also used in various duties in civil variants, as trainers and in many secondary roles. Successful in the Spanish Civil War because it outpaced most fighters, the aircraft was obsolete by 1941.[clarification needed] By June 1941, 94 percent of bombers in the Red Army air force (VVS RKKA) were SBs.
Controls:
AG1> Open Bomb Bay
VTOL> Gun Elevation

General Characteristics

  • Created On Android
  • Wingspan 125.5ft (38.3m)
  • Length 76.5ft (23.3m)
  • Height 27.9ft (8.5m)
  • Empty Weight N/A
  • Loaded Weight 87,695lbs (39,778kg)

Performance

  • Horse Power/Weight Ratio 0.285
  • Wing Loading 38.3lbs/ft2 (187.0kg/m2)
  • Wing Area 2,289.7ft2 (212.7m2)
  • Drag Points 41878

Parts

  • Number of Parts 506
  • Control Surfaces 0
  • Performance Cost 1,843
