Martadinata Class Frigate

5,309 Sylver  3.7 years ago
4,004 downloads

Characteristics

The R.E. Martadinata class of guided-missile frigates of the Indonesian Navy are SIGMA 10514 types of the Netherlands-designed Sigma family of modular naval vessels, named after Indonesian Admiral Raden Eddy Martadinata. The frigates are each built from six modules or sections, four built at the PT PAL shipyard at Surabaya, the other two at Damen Schelde Naval Shipbuilding in the Netherlands.Currently only two R.E. Martadinata-class frigates have been ordered, however, with the planned retirement of the Ahmad Yani-class frigates it is widely expected that more R.E. Martadinata-class frigates will be ordered and built.

Specifications

Displacement: 2,365 tons
Length: 105.11 m (344 ft 10 in)
Propulsion: CODOE 2 x 10000 kW MCR diesel propulsion & 2 x 1300 kW MCR electric propulsion
Maximum speed: 28 knots (52 km/h; 32 mph)
Range: 5,000 nmi (9,300 km; 5,800 mi) at 14 knots

Armaments

•Melara Rapid (76mm)
•Oerlikon millenium (CIWS)
•Exocet MM40 Block 2
•VLS-Mica
•Eurotorp B515 (Torpedo)
•Drones

CONTROL

AG 1 = Run The Ship
AG 2 = Exocet MM40 Block 2
AG 3 = Open Door
AG 4 = Open Door
AG 5 = Drone 1 / Cam 1 + Cam 2 (Kamikaze Drone)
AG 6 = Drone 2 / Cam 3 + Cam 4 (Kamikaze Drone)

Martadinata Class 3.0

Spotlights

General Characteristics

  • Successors 4 airplane(s) +77 bonus
  • Created On Android
  • Wingspan 34.4ft (10.5m)
  • Length 332.4ft (101.3m)
  • Height 97.7ft (29.8m)
  • Empty Weight 161,164lbs (73,103kg)
  • Loaded Weight 173,913lbs (78,885kg)

Performance

  • Power/Weight Ratio 0.581
  • Horse Power/Weight Ratio 0.011
  • Wing Loading 6.3lbs/ft2 (30.8kg/m2)
  • Wing Area 27,556.3ft2 (2,560.1m2)
  • Drag Points 164846

Parts

  • Number of Parts 795
  • Control Surfaces 12
  • Performance Cost 2,807
