SAAB J-35D Draken

This build is from 2021 that I forgot to finish.
It's finally out, but the reason it took 2.5 years to finish it doesn't mean I was constantly improving it, I just forgot.

Disclaimer: The Draken by nature is unstable, I do not recommend controlling this aircraft with a keyboard.

(The Draken in reality is even more unstable, mine is a bit too stable especially in terms of how it is pretty much immune to flat spins )

Different Versions (Bicolour Scheme / Low part versions)

Bicolour skin build 1352 parts

Bicolour skin build 1097 parts

Chrome skin build 1297 parts

Chrome skin build 952 parts

WiP

I kinda gave up on this thing

There's a lot stuff that are missing

Flight Model

Please note that the Draken pulls a lot of AoA, and is very sensitive, especially at low speeds (around 600km/h and lower)

High speed maneuvers are at around 11~12Gs (The aircraft may exceed 12Gs for a split second in a high speed turn)

Do not exceed IAS 1420km/h as the control surfaces will lock up.
(Should've added wing rips but...lazy)

Cobra

As there are no such thing as a AoA limiter in this aircraft, to perform a cobra in this aircraft, decrease the throttle down to 30%~50% or lower, and simply adjust your IAS to around 350~400km/h, and pull as hard as you can.

Increase thrust after the maneuver as soon as possible Do not maintain the pitch for too long, as it will lead to unrecoverable stalls, sometimes a flat spin.

Flatspin recovery:
Apply maximum thrust
Apply Roll, Yaw to the direction of spin, Pitch down.
(Do not try to counter roll/yaw)

Engine

Replication of the Volvo RM6C in terms of thrust, fuel consumption etc

No fancy start up procedures, but IAS and altitude will affect thrust, fuel consumption

Thrust will gradually increase until it hits around IAS 1200km/h at deck.

Thrust, Fuel consumption will decrease by around 3% every 1000 meters, until around 15000+meters, it will not ignite.

Controls

AG1 - Low sensitivity controls
AG2 -
AG3-
AG4- Jettison RB-24Js
AG5- Ram Air Turbine (Does nothing but popping a mini fan behind the front gear)
AG6- AirBrakes
AG7- Drogue Chute
AG8- Open / Close Canopy

Ejection Seat

Activated by Eject in weapons tab

Cockpit sucks lol most stuff aren't functional (Radar, AoA indicator, Landing Gear warning light etc)

Versions

Bicolour skin build

Bicolour skin build 1352 parts

Bicolour skin build 1097 parts

Chrome skin build 1297 parts

Chrome skin build 952 parts

HEJ DÅ !

Spotlights

General Characteristics

  • Successors 2 airplane(s) +14 bonus
  • Created On Windows
  • Wingspan 30.4ft (9.3m)
  • Length 50.3ft (15.3m)
  • Height 14.7ft (4.5m)
  • Empty Weight 19,054lbs (8,642kg)
  • Loaded Weight 22,599lbs (10,250kg)

Performance

  • Power/Weight Ratio 477322.944
  • Wing Loading 53.5lbs/ft2 (261.4kg/m2)
  • Wing Area 422.1ft2 (39.2m2)
  • Drag Points 240

Parts

  • Number of Parts 1582
  • Control Surfaces 1
  • Performance Cost 5,524
  • Log in to leave a comment
  • Profile image
    13.6k brians1209

    @Zal777

    About the instabilities:
    .
    Let me explain again. Similar complaints have been received before. Also, the SAAB J-35 Draken does not have flaps, just as most other double delta/delta wing aircrafts.
    .
    The J-35D Draken is unstable by its very nature.
    .
    The CoM of the Draken is shifted to the rear of the aircraft (not to exclude most of the body being a massive LERX), making it unstable, and prone to unrecoverable flat spins (Some Drakens were equipped with chutes to deploy at air when caught in a flat spin)
    The cobra maneuver of the Draken wasn't on purpose, it was rather considered as a flaw. But with these intentional instabilities and 'flaws' the Draken came with excellent maneuverability.
    .
    The Draken in reality is even more unstable, much easier to stall and fall into a flatspin. Most modern fighters are intentionally built to be unstable (relaxed instability), but controlled by a flight computer to be stable in flight. The Draken does not have such technology. (At least the Draken's CoL is behind the CoM, the F-16 for example has the CoM behind the CoL).
    .
    To put it another way, Draken pilots had to 'trim' the aircraft to do the same maneuvers in which other aircraft required the whole flight stick to be involved.
    .
    TL;DR I would go as far to say that my Draken isn't unstable enough, and I wouldn't try controlling this with a keyboard.
    .
    Even aircrafts that are more stable than the Draken in real life does not control like you would imagine in real life.
    .
    It took some effort to make it purposefully unstable whilst flyable in SP.
    I hope you understood.

    Pinned 10 months ago
